Grundfos 98126828 GRU98126828
Grundfos MAGNA 3 Series MAGNA3 40-80 F 98126828 Circulator Pump, 81 gpm, 16 to 262 W, 208-230 V, 0.19 to 1.2 A, 60 Hz
- Manufacturer: Grundfos
- Brand Name: Grundfos
- Part#: GRU98126828
- MPN: 98126828
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
MAGNA3 - more than a pump with its unrivalled efficiency, all-encompassing range and built-in communication capabilities plus functionalities replacing system components, the MAGNA3 is ideal for engineers and specifiers looking to create high performance systems for buildings. This pump in the grundfos Master class will fit both heating and cooling applications perfectly, making it the obvious choice for almost any building project - old or new. The MAGNA3 is of the canned rotor type, that is pump and motor form an integral unit without shaft seal and with only Two-gaskets for sealing. The bearings are lubricated by the pumped liquid. The innovative clamp with only one screw enables easy repositioning of the pump head. The MAGNA3 is a pump with no maintenance requirements and with extremely low life cycle cost.
Grundfos Circulator Pump, MAGNA 3 Series, Model: MAGNA3 40-80 F, 81 gpm Flow Rate, 40 mm Inlet, 40 mm Outlet, 26-1/4 ft Maximum Head, 16 to 262 W, 208-230 V, 0.19 to 1.2 A, 60 Hz, 175 psi Maximum Pressure, 4320 rpm Motor Speed Rating, 1/3 hp, GF15/26/40/43 Connection, Flanged Connection, 1 ph Phase, 4 Poles, 104 deg F Ambient, 230 deg F Liquid, Iron, 374 mm W, Additional Information: Glass-Filled PES Impeller Material
| Additional Information | : | Glass-Filled PES Impeller Material |
| Amperage Rating | : | 0.19 to 1.2 A |
| Body Material | : | Iron |
| Connection Size | : | GF15/26/40/43 |
| Connection Type | : | Flanged |
| Dimensions | : | 374 mm W |
| Discharge Size | : | 40 mm Dia |
| Flow Rate | : | 81 gpm |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1/3 hp |
| Impeller Material | : | 30% Glass-Filled PES |
| Inlet Size | : | 40 mm |
| Material | : | Iron |
| Maximum Head | : | 26-1/4 ft |
| Maximum Pressure | : | 175 psi |
| Model | : | MAGNA3 40-80 F |
| Motor Speed Rating | : | rpm |
| Number of Poles | : | 4 |
| Outlet Size | : | 40 mm |
| Phase | : | 1 ph |
| Power Rating | : | 16 to 262 W |
| Pressure Rating | : | 175 psi |
| Series | : | MAGNA 3 Series |
| Suction Size | : | 40 mm Dia |
| Temperature Rating | : | 104 deg F Ambient, 230 deg F Liquid Enclosure Type |
| Voltage Rating | : | 208-230 V |
- Flow adapt and flow limit
