Grundfos 52722514 GRU52722514
Grundfos Large Stator UP Series UPS 43-44 FC 52722514 Circulator Pump, 63 gpm, 203 W, 115 V, 1.4/1.7/1.8 A, 60 Hz, Iron
- Manufacturer: Grundfos
- Brand Name: Grundfos
- Part#: GRU52722514
- MPN: 52722514
- UPC: 632514160767
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
Grundfos Circulator Pump, Large Stator UP Series, Model: UPS 43-44 FC, 63 gpm Flow Rate, 14.11 ft Maximum Head, 203 W, 115 V, 1.4/1.7/1.8 A, 60 Hz, 145 psi Maximum Pressure, 3360 rpm Motor Speed Rating, 0.16 hp, 1/2 in Connection, Flanged Connection, 1 ph Phase, 2 Poles, 104 deg F Ambient, 230 deg F Liquid, Iron, 6.69 in H x 8.5 in W, Additional Information: PES Impeller Material
| Additional Information | : | PES Impeller Material |
| Amperage Rating | : | 1.4/1.7/1.8 A |
| Connection Size | : | 1/2 in |
| Connection Type | : | Flanged |
| Dimensions | : | 6.69 in H x 8.5 in W |
| Flow Rate | : | 63 gpm |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 0.16 hp |
| Material | : | Iron |
| Maximum Head | : | 14.11 ft |
| Maximum Pressure | : | 145 psi |
| Model | : | UPS 43-44 FC |
| Motor Speed Rating | : | rpm |
| Number of Poles | : | 2 |
| Phase | : | 1 ph |
| Power Rating | : | 203 W |
| Series | : | Large Stator UP Series |
| Temperature Rating | : | 104 deg F Ambient, 230 deg F Liquid Enclosure Type |
| Voltage Rating | : | 115 V |
- With integral check valve
