Grundfos 59896775 GRU59896775
Grundfos Small Stator UP Series UP 15-29 SU 59896775 Circulator Pump, 0 to 22 gpm, 87 W, 115 V, 0.75 A, 60 Hz
- Manufacturer: Grundfos
- Brand Name: Grundfos
- Part#: GRU59896775
- MPN: 59896775
- UPC: 632514174535
- Min. Order Qty: 1
- Qty. Interval: 1
-
Availability:
- Branch Availability
-
Price:
Grundfos Circulator Pump, Small Stator UP Series, Model: UP 15-29 SU, 0 to 22 gpm Flow Rate, 10 ft Maximum Head, 87 W, 115 V, 0.75 A, 60 Hz, 145 psi Maximum Pressure, 0.121 hp, 1-1/4 in Connection, NPSM x Union Connection, 1 ph Phase, 2 Poles, 104 deg F Ambient, 230 deg F Liquid, Stainless Steel, 5-7/8 in H x 5-1/2 in W x 3-7/16 in D, Additional Information: Composite/PES Impeller Material
| Additional Information | : | Composite/PES Impeller Material |
| Amperage Rating | : | 0.75 A |
| Connection Size | : | 1-1/4 in |
| Connection Type | : | NPSM x Union |
| Dimensions | : | 5-7/8 in H x 5-1/2 in W x 3-7/16 in D |
| Flow Rate | : | 0 to 22 gpm |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 0.121 hp |
| Material | : | Stainless Steel |
| Maximum Head | : | 10 ft |
| Maximum Pressure | : | 145 psi |
| Model | : | UP 15-29 SU |
| Number of Poles | : | 2 |
| Phase | : | 1 ph |
| Power Rating | : | 87 W |
| Series | : | Small Stator UP Series |
| Temperature Rating | : | 104 deg F Ambient, 230 deg F Liquid Enclosure Type |
| Voltage Rating | : | 115 V |
- Stainless steel pump housing
Instruction/Installation Manual
